Manhole lifting pins are designed to assist the safe lifting and positioning of concrete manhole chambers. At DRE we stock two types of Manhole lifting Pin.
• The Latch Type manhole lifting pin mechanism makes it faster and safer when lifting Concrete pipes. The pin features an automatic drop latch which secures the pin in the manhole
• The Basic Type manhole lifting pins provide good value for money compared with the latch type. They are designed to be used in three’s and come with certification
Concrete Manhole Lifting Pins
Description
Concrete Manhole Lifting Pins are designed to assist the safe lifting and positioning of concrete manhole chambers. At Dermot Redmond Engineering Ltd we stock two types of Concrete Manhole Lifting Pins.
- The Latch Type manhole lifting pin mechanism makes it faster and safer when lifting Concrete pipes. The pin features an automatic drop latch which secures the pin in the manhole.
- The Basic Type manhole lifting pins provide good value for money compared with the latch type. They are designed to be used in three’s and come with certification
| Type | Shaft | Diameter | SWL |
|---|---|---|---|
| Basic | 210mm | 30mm | 1500kg |
| Latch | 160mm | 25mm | 750kg |
| Latch | 195mm | 32mm | 1000kg |
| Latch | 220mm | 35mm | 1500kg |
| Latch | 250mm | 38mm | 2000kg |
